MT-MT
MT-MT is mainly used for a parallel optical technology module (QSFP) which connects the internal optical lens and external port to meet the signal transmission of the optical module. By miniaturization, high precision and customized design, MT short jumper solves the contradiction between the limited space inside the high-speed optical module and the high-density wiring.
-
Product Feature
-
Product Application
-
Specification
-
Related Products
-
Related Solutions
Product Feature
-
Comply with IEC-61754-7, GR-468-CORE, RoHS
-
Quick insertion and withdraw, easy to operate
-
Low insertion loss and high return loss
Product Application
-
Optical module, AOC, Switching equipment
-
Application of parallel data exchange between PC
-
40G/100G/400G/800G network transmission
-
Optical fiber distribution system
Specification
| Test Items | SM | MM | ||
|---|---|---|---|---|
| Insertion Loss (dB) | Standard | Elite/Low | Standard | Elite/Low |
| ≤0.70 | ≤0.35 | ≤0.50 | ≤0.35 | |
| Return Loss (dB) | ≥60 | ≥20 | ||
| Durability (times) | ≥200 | |||
| Operating Temperature (℃) | -25 ~ +70 | |||
| Test Wavelength (nm) | 1310/1550 | 850/1300 | ||
