MPO/MTP Trunk Cable Assembly

MPO/MTP® cable assembly use MTP® or MPO multi-fiber connectors to provide a high-density solution. Based on single ferrule MT technology, the MPO cable assemblies provide up to 72 fiber connections in a single point, saving the space and reducing cable management troubles, while providing the same bandwidth capacity of a multi-fiber cable with individual fiber connector terminations per cable. It is suitable for telecom, data center, datacom, used to connect within cabinet, or connectivity between of longer building, and interconnect MPO cassettes of SFP module.

NEOPTICS MPO/MTP® cable assemblies comply with IEC61754, IEC61755, GR1435, TIA568 standards, and adopts a push-pull locking structure with male and female heads to ensure butt tightness and low loss.

Consult

Product Feature
Product Application
Specification
Related Products
Related Solutions

Product Feature

Quick insertion and withdraw, easy to operate
High cabling density, can provide 12 to 144 core fiber connection, saving cabling space
Low insertion loss and high return loss
Comply with IEC-61754-7, GR-1435-CORE, RoHS

Product Application

Data center LAN system
Application of parallel data exchange between PC
10G/40G/100G/400G network transmission
Optical fiber distribution system

Specification

Test Items	SM		MM
Insertion Loss (dB)	Standard	Elite/Low	Standard	Elite/Low
Insertion Loss (dB)	≤0.70	≤0.35	≤0.50	≤0.35
Return Loss (dB)	≥60		≥20
Durability (times)	≥200
Operating Temperature (℃)	-25 ~ +70
Test Wavelength (nm)	1310/1550		850/1300
