ODVA Outdoor Cable Assembly

With a special mechanical sealing structure, waterproof, dustproof, UV protection, cable assembly is suitable for outdoor environments with variable conditions.

Consult

Product Feature
Product Application
Specification
Related Products
Related Solutions

Product Feature

IP67 water and dust protection
UV resistant, rat-bite resistant
Suitable for outdoor environments with variable conditions
Factory-assembled cables for a fast on-site installation
Various connector available, such as MPO/LC/SC, etc

Product Application

Multifunctional outdoor patchcord
It is used to connect the distribution box to the RRH
Applied to remote wireless base station

Specification

Fiber Mode	SM		MM
End-face Finishing	UPC	APC	PC
Insertion Loss (dB)	≤0.30	≤0.30	≤0.30
Return Loss (dB)	≥50	≥60	≥35
Exchangeability (dB)	≤0.20
Repeatability (dB)	≤0.20
Operating Temperature (℃)	-40 ~ + 80
Operating Wavelength (nm)	1310, 1550		850, 1300
Tensile Strength (N)	≥300

Consult

Related Solutions

5G Base Station

In response to the application requirements of 5G's high bandwidth, low latency, and massive connections, NEOPTICS provides solutions that cover a variety of 5G application scenarios based on Carrier Network Access Stratum.

Learn More
FTTX Cabling Solution

FTTX uses optical fiber as the transmission medium and has the advantages of large transmission capacity, high transmission quality, high reliability, long transmission distance and anti electromagnetic interference.

Learn More
